Thermal rifle scope Hikmicro NEOS NH25L

Hikmicro Neos is a powerful thermal riflescope with a sensitive core, long detection range and a bunch of advanced features designed for precise shooting where standard daytime optics are not enough.

The NH25L model, the mid-range version in the NEOS class, combines a 25 mm objective lens, a sensitive thermal core and a full set of features including a laser rangefinder and ballistic calculator.

Sensitive thermal core and 25 mm objective lens

The scope is based on a thermal sensor with a resolution of 320 × 240 px, 12 μm pixel pitch and thermal sensitivity NETD < 18 mK (the lower the value, the more sensitive it is). Thanks to this, it can clearly render even fine temperature differences in the observed scene and helps to distinguish the target from the surroundings more easily.

The 25 mm F1.0 objective lens gives the NH25L model a detection range of up to 1200 m. Magnification ranges from 3.5-24.5x (using 8x digital zoom).

AMOLED display and colour modes

The resulting image is transmitted to a 0.49" 1920x1080px AMOLED display. The display is complemented by brightness and contrast adjustment and dioptre correction in the range from −4 D to +4 D.

There are 6 colour palettes available – Black Hot, White Hot, Red Hot, Fusion, Red Monochrome and Green Monochrome. You can also choose between 11 reticle types and several reticle colours. This allows the display to be adapted to the type of scene, surrounding contrast and the way of observation.

There are 5 zeroing profiles available. The Freeze Zeroing function freezes the image while zeroing, allowing you to adjust the position of the reticle relative to the point of impact more precisely, without disturbing movement in the live image.

Hikmicro image technologies

Image quality and smoothness are ensured by a combination of functions Image Pro 3.0, Zoom Pro, HSIS and Sync Pro. Image Pro 3.0 helps to enhance details in the thermal image, and Zoom Pro improves readability at digital magnification.

The HSIS technology reduces disturbing image interruptions during calibration and helps maintain a smooth thermal image. The Sync Pro function focuses on fast real-time image synchronisation so that the display matches the observed scene as closely as possible.

Laser rangefinder and ballistic calculator

The integrated laser rangefinder measures distance in the range of 10 to 1000 m with an accuracy of ±1 m. It uses a class 1 laser with a wavelength of 905 nm and supports quick distance measurement directly in the image.

The rangefinder is linked to the ballistic calculator – after measuring the target distance with the laser rangefinder and entering the required values (bullet ballistic coefficient, muzzle velocity and similar), the device shows the point of impact directly on the display.

Recording, memory and mobile app

The riflescope allows you to take photos, record video with sound and save footage to the 64GB internal memory. The Recoil-activation Recording function starts recording when a shot is fired, so you can capture the crucial moment without manually starting the recording.

Via the built-in Wi-Fi hotspot, Hikmicro Neos can be connected to the HIKMICRO Sight app. The app is used for working with recordings, sharing content, adjusting settings and also for reticle correction.

Durable and lightweight design

The construction with a 30 mm tube is made of aluminium alloy with a matte black anodised finish and has protection rating IP67. It can operate in a temperature range from −30 °C to +55 °C and withstands recoil of 1000 g / 0.4 ms.

Power supply combines a built-in rechargeable Li-Ion battery and a replaceable rechargeable 18650 battery. The NH35L model offers up to 9 hours of runtime with Zoom Pro and LRF turned on. Power and data transfer are provided via a USB-C interface with QC3.0 support.

Parameters and differences between versions
